InGaAs APD & Pin photodiode
1.25G ROSA photo diode
Item No.: 186
1.25G ROSA photo diode
Description
Product details
Place of Origin: India or China
Model Number: DTNT-TOROSA
Specifications
- 20 years experence in making optical diode
- workable price
- has 1 years warranty period
- Complied with ROHS
Model Number: DTNT-TOROSA
Specifications
- 20 years experence in making optical diode
- workable price
- has 1 years warranty period
- Complied with ROHS
Features
- Low Capacitance: ≤1pF
- 2GHz Frequency Response
- Low Dark Current, Low Back Reflection
- High Responsivity: ≥0.85A/W 1310nm ≥0.90A/W 1550nm
- Laser Welding, Coaxial Package
- High Reliability and Long Operation Life
- Various Connector Type: FC,SC,ST,LC,MU
- Low dark current and high linearity
Application
- CATV Forward/Return Path
- QAM 64/256 System
- PON
- FTTH Network
- EDFA Monitors
- Absolute Maximum Rating: (Tc=25°C)
Supply Ability
100K PCS/Month
Packaging Details
Pack in static electricity package
Packaging
- Pack in static electricity package, according to customer packing requirement
- Lead Time : 3 days after receiving payment
- Low Capacitance: ≤1pF
- 2GHz Frequency Response
- Low Dark Current, Low Back Reflection
- High Responsivity: ≥0.85A/W 1310nm ≥0.90A/W 1550nm
- Laser Welding, Coaxial Package
- High Reliability and Long Operation Life
- Various Connector Type: FC,SC,ST,LC,MU
- Low dark current and high linearity
Application
- CATV Forward/Return Path
- QAM 64/256 System
- PON
- FTTH Network
- EDFA Monitors
- Absolute Maximum Rating: (Tc=25°C)
Supply Ability
100K PCS/Month
Packaging Details
Pack in static electricity package
Packaging
- Pack in static electricity package, according to customer packing requirement
- Lead Time : 3 days after receiving payment
| Parameter | Symbol | Min. | Max. | Unit |
| Operating Temperature Range | Top | -40 | +85 | °C |
| Storage Temperature Range | Tstg | -40 | +85 | °C |
| Soldering Temperature Tmax= 10s | Ts | - | 260 | °C |
| Forward Current | Ifd | - | 10 | mA |
| Reverse Voltage | Vrd | - | 25 | V |
| Saturation Input Power | Psat | - | 10 | mW |
